GS 600/5-FDT

ALZMETALL-Gantry-Conzept (AGK)

  • Grey Cast Iron and Spheroidal Graphite Cast Iron
  • Monobloc Travel-System-Carriage with incorporated Box-in-Box-System
  • 2-fold Linear Guidance for X-Y-Travel System-Carriage and 4-fold Linear Guidance for Z-Axis with Travel-System-Carriage with integrated Motor-Spindle
  • 3-fold Torque-Drives for Swivel-Axis (A-Axis) and Rotary-Axis (C-Axis) at GS 600/5-T und GS 600/5-FDT
  • Hybrid-Machining-Applications such as: Drilling/Milling/Turning and Grinding at one Clamping-Set-Up
  • Up to 500 kg workpiece weight including Clamping-Set-Up-Device at 5-Axis Machines
Request product
Y-Axis

Z-Axis

Interference circle diameter

Distance Spindle

Machine-Table Load

Maximum rapid travel X/Y/Z at TCP max.

Cutting-Tool Interface

Motor-Spindle-Power at CDF 25% max.

Variable Speed Range max.

Motor-Spindle Torque at CDF 25% max.

  • NC - Swivel - (A-Axis) and Rotary-Tables (C-Axis: Table-Set: Rotary-Table C-Axis, Rotary-Table C-Axis with NPS
  • CNC-Controls - Heidenhain TNC 640 (Standard)
  • CNC-Controls Siemens SINUMERIK 840 D sl
  • KINEMATIK Gauging
  • Electrical Handwheels
  • 3D -Touch Probes Infrared transmission
  • Multiple-Media-Coupling
  • Tool Setting System
  • Camera and Screen
  • Tool-Magazines: Twin-Disc-Tool Magazine with 76 Tool Positions
  • Tool-Magazines: Rack-Type Magazines designed for 224 Tool Positions
  • Operating Supply Unit Set‘s: Bundle set‘s A, B, C cooling and cleaning circuit system up to 80 bar high pressure, on selection Scratch-Type or Hinge-Type-Conveyor
  • Mist Extraction Unit
  • Remote Diagnosis and Maintenance
  • Machining Center Acceptance: Workpiece according to ALZMETALL-Standard, on selection Customer-Workpiece (option)
  • Services: NC-Program-Training, Operator-Training for Heidenhain and Siemens and Machining Center Installation and Commissioning, Process development, Production Assistance, Service and Maintenance
  • More Services: Cutting-Tool Setting and Detection, Mist Extraction Units, Equipment for Graphite Machining, Custom-Made Solutions
